80~600%电流转换比,光电耦合器

概述
FT-X2-PC817是一款由一个发光二极管和一个光电晶体管组成的光电耦合器。四引脚封装,两种材料(铜脚、铁脚,铜脚尾缀-G)三种形式(DIP、DIP-M、SMD)

特性
 电流转换比 (CTR)范围: 80~600% (IF =5mA ,VCE =5V)
 输入-输出隔离电压 (Viso=5000 Vrms)
 集电极-发射极击穿电压 BVCEO≥80V
 UL 认证(NO.:E497745)
 符合EU REACH 和RoHS
 CQC 认证(NO:CQC20001238665)

Applications
 开关电源,智能电表
 工业控制,测量仪器
 办公设备,比如复印机
 家用电器,比如空调、风扇、热水器等









Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks poliFT-X2- of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
