Features
■ Two isolated channels per package
■ Two packages fit into a 16 lead DIP socket
■ Choice of three current transfer ratios
■ Underwriters Laboratory (U.L.) recognized File E90700
Applications
■ AC Line/Digital Logic – Isolate high voltage transients
■ Digital Logic/Digital Logic – Eliminate spurious grounds
■ Digital Logic/AC Triac Control – Isolate high voltage transients
■ Twisted pair line receiver – Eliminate ground loop feedthrough
■ Telephone/Telegraph line receiver – Isolate high voltage transients
■ High Frequency Power Supply Feedback Control – Maintain floating grounds and transients
■ Relay contact monitor – Isolate floating grounds and transients
■ Power supply monitor – Isolate transients
Description
The MCT6X Optocouplers have two channels for density applications. For four channel applications,two-packages fit into a standard 16-pin DIP socket. Each channel is an NPN silicon planar phototransistor optically coupled to a gallium arsenide infrared emitting diode.
