可控硅输出光耦FT-X2-TLP160

概述
FT-X2-TLP160系列产品由一个砷化镓红外发光二极管和一个双向光可控硅组成的光电耦合器。

特性
 峰值击穿电压:400V(min.)
 输入-输出隔离电压 (Viso=3750V rms )
 LED 触发电流 :10mA(max.)
 开态电流 :70mA(max.)
 UL 认证 (NO:E497745)
 符合EU REACH 和RoHS
 CQC 认证(NO:CQC20001238559)

典型应用
 隔离线接收器
 电磁/阀控制
 光控制
 静态电源开关
 电机驱动
 EM 接触器
 温度控制
 交流电动机启动器
 固态继电器











Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
