1.Features
(1). High speed - 1MBd model.
(2). Adapted to the dual-in-line, lead spacing width, surface installation.
(3). Store output.
(4). UL, VDE approval.
(5). MSL Class Ⅰ
2.Instructions
FT-88-M501consists of highly efficient AlGaAs light-emitting diodes and high-speed optical detectors. The design provides good ac and dc isolation at the input and output ends of the photoelectric coupler. Connections related to photodiode biasing can improve the speed of conventional phototransistor couplers by reducing the capacitance of the matrix collector. Internal shielding ensures high transient immunity in general mode. Ensure the common-mode transient immunity to 1 kv/μsec.
3.Application Range
- line receiver isolation
- switching power supply
- motor control system
