产品特点
高电流传输比:1800%(典型值)
隔离电压:1000V
集电极开路反相输出
低电流驱动:0.5mA
TTL/ LSTTL/CMOS等电路兼容
产品应用
军事和空间技术
微处理系统接口
电流回路接收器
系统测试设备隔离
程序控制中输入/输出隔离
国产军品三端达林顿输出型光耦是北亿纤通研发生产的一款国产军品光耦，分为两类：一类为输出两端口，最大工作电压50V，传输比>2000%；一类为输出三端口，最大工作电压18V，传输比>500%；都有 1~32路可选
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
